Jual HRLM LBZ - A1D2K1 EXPLOSION PROOF LOCAL CONTROL STATION ( IIB ) Jakarta Indonesia
APPLICATION :
* Designed for Explosive Atmosphere Zone 1, Zone 2
* Designed for Groups IIA, IIB, and Temperature classes T1 - T6
* Designed for Petroleum Exploitation, Refinery, Chemistry Medicine, Textile, Painting, Military and Military Facilities etc, Sites with Explosive Atmosphere.
* Widely used in industry control circuit.
* Different types, can be designed as per client's electrical systematic drawing
ORDERING REFERENCES
* Can be used indoors and outdoors. If used outdoors the rain resistance cover is recommended to used.
* Only components type and number will be showed on nameplate, detail specification for components are only for ordering specification.
* Potentiometer is only for IV, V
FEATURES :
* Enclosure is die casted of alluminium alloy, high voltage electrostatic powder coated surface after shot blasted.
* Built-in component including indicator, pushbutton, changeover switch, ammeter, voltmeter, potensiometer, etc. And other components as per request.
* Over 30 types functions for changeover switch for client selection.
* Rain resistance cover can be equipped as per request.
* Specially designed seal structure efficienctly improve ingress protection and meet the explosion protection requeirements.
* Hinge between cover and enclosure easy to maintain.
* Steel pipe and cable wiring.
TECHNICAL SPECIFICATION
* Compliance with : GB 3836. 1, GB 3836. 2, GB 3836. 3, GB 12476. 1, IEC60079-0, IEC-60079-1, IEC-60079-7
* Explosion Protection : Exd II BT6
* Rated Voltage : AC 220/380V
* Rated Currrent : 10A
* Using Sort : AC-14
* Ingress Protection : IP55
* Corrosion Resistance : WF1
* Enclosure Types : I, II, III, IV, V
* Cable Entries Specification : G1", G2"
